Playback

From Audacity Development Manual
Jump to: navigation, search
This page provides a detailed description of various ways of controlling playback in Audacity, including keyboard shortcut commands and how to play short periods around selections.

Contents

  1. Play button
  2. Playback Regions, Quick-Play Regions and Play Regions
  3. Keyboard commands to skip playback position by specified short and long periods
  4. Play relative to mouse pointer or selection
  5. Play short periods around selections
  6. Mute and Solo buttons
  7. Additional Playback Tips


Play button

The easiest way to control Audacity playback is with Transport Toolbar:

Annotated Transport Toolbar.png
The Play button Clicking Play plays from the cursor point to the end of the project, or from the start of the selection region to the end of that region.
The Loop Play button The alternative Loop Play action for the Play button is activated by holding Shift while clicking Play. The button changes to display two circular green arrows to indicate Loop Play.
The Play Cut Preview button Play Cut Preview will play audio either side of a selection to preview what deleting the selection will sound like. Hold down Ctrl ( on Mac) while clicking Play.
Alternatively you can use the C shortcut to preview the cut. This also causes the Play button image to change to Play Cut Preview.
Clicking Play when the track is already playing or paused is a quick way to restart playback without first pressing Stop.
The Pause button Click Pause, or its shortcut P, to temporarily pause playing or recording without losing your place. Click Pause a second time to resume.
The Stop button Clicking Stop stops playing or recording immediately, and releases Pause if depressed. You must stop playback or recording before you can use the Skip buttons in the Transport Toolbar.
The shortcut Space can be used to either play or stop. After stopping, playback resumes from its last starting point.
Alternatively, use X or Transport > Playing > Play/Stop and Set Cursor to stop playback and set the cursor there. Playback will resume from the stop point on pressing Play.
To change the starting point to anywhere you like, click in the track at your desired starting point, then use Space to play from there.

Playback Regions, Quick-Play Regions and Play Regions

The standard playback region associated with a shaded selection region in the waveform is indicated in the Timeline by a thin horizontal gray bar with arrowheads on each end. For example in the image below, a region from 9 to 31 seconds.has been drawn in the waveform, and the matching arrowed region in the Timeline also extends from 9 to 31 seconds. This region will always play once when you press Space or a Play button.


If there is only an editing cursor in the waveform, playback always starts from that cursor position and continues until the end of the project (unless you stop playback).

Whenever audio is played, a green downward-pointing triangle shows the current audio playback position. In the image below, playback starts at 9 seconds at the position of the editing cursor (represented in the Timeline by a black vertical line with left-pointing arrowhead). Playback had reached 14 seconds when the image was taken.


There may be times when you want to move around to hear arbitrary parts of the audio while still retaining the position of the editing cursor or region in the waveform. Quick-Play lets you drag in the Timeline to play that region immediately (or lets you click to start playback at that point immediately), without moving the waveform region or cursor and without having to stop and restart playback.

Quick-Play does not operate when Audacity is recording.

In the image below we dragged a Quick-Play region to play from 13 to 37 seconds. That region is indicated in the Timeline by a thick horizontal gray bar with arrowheads on each end, and playback was at 19 seconds when the image was taken.


If you hear some important audio during Quick-Play you can move the waveform region or cursor to that point without affecting Quick-Play playback, but this still allows you to restart standard playback from the important spot.

On occasion you may always want to play the exact same region, even if the region or cursor in the waveform is elsewhere. You can use Transport > Play Region > Lock to lock playback to the current playback region (or to the current position of the Quick-Play region). The locked region is indicated in the Timeline by a thick horizontal red bar with arrowheads on each end. In the image below, playback will always occur from 13 to 28 seconds until Transport > Play Region > Unlock is used to release the Play Region.


Keyboard commands to skip playback position by specified short and long periods

These commands skip the playback cursor backwards (left) or forwards (right) by a short or long period of time. The default short period skipped is one second and the default long period skipped is 15 seconds. You can change the length of the default short or long period to be skipped at "Seek Time when playing" in the Playback Preferences.

Action Shortcut
Short seek backwards Left or ,
Short seek forwards Right or .
Long seek backwards Shift + Left or Shift + ,
Long seek forwards Shift + Right or Shift + .
Warning icon

You cannot seek backwards to left of the current position of the playback cursor.

Play relative to mouse pointer or selection

These are three keyboard commands that let you play a few seconds of audio without changing the selection. They can be really useful during editing, such as when you are trying to find the exact spot to cut and paste.

Action Shortcut
Play One Second 1
Play To Selection B
Play Cut Preview C

Play One Second (1)

Press 1 while the mouse is pointing to a particular point on the Timeline, and you will hear one second of audio centered on that time. The mouse does not need to be over the waveform itself, and the pointer can be inside a selection, so giving you a way to play one second of that selection, centered on the pointer. For example, position the mouse at 1.0 seconds and press 1 , and you will hear the time range from 0.5 to 1.5 seconds (below).


Play To Selection (B)


Suppose you have selected a range of audio (above), and you want to make sure it is exactly what you want to cut out. In order to determine whether you have selected exactly the right range of audio, you can not only listen to the selection, but you can position the mouse pointer so as to listen to any desired length of audio before or after the selection.

If you press Space, you will hear the whole selection (indicated by the playback region shown in the Timeline) (below).




The "B" key lets you play the audio between the mouse pointer and the selection - what you hear depends on where the mouse pointer is. Move the mouse to a part of the audio you are interested in hearing, and press B, without clicking the mouse button (the first through the fourth images below).

If the mouse pointer is to the left of the selection and you press B, you will hear the audio up to the selection.


If the mouse pointer is inside the left side of the selection and you press B, you will hear the first part of the selection up to the mouse pointer.


If the mouse pointer is inside the right side of the selection and you press B, you will hear from the mouse pointer to the end of the selection.


Finally if the mouse pointer is to the right of the selection and you press B, you will hear from the selection to the mouse pointer.


B works in the same way to play to the cursor when there is no selection. If you place the pointer before the cursor, B plays from the pointer to the cursor. If you place the cursor after the pointer, B plays from the cursor to the pointer.

Play Cut Preview (C)

Press the C key to hear two seconds of audio before the selection and then one second of audio after the selection - thus simulating what playback would sound like if the selection was deleted. If you have multiple tracks selected, only the uppermost of the selected tracks is previewed. You can change the length of the audio that is played before and after the selection in Playback Preferences.

If preferred, Play Cut Preview of a selection can also be performed by holding Ctrl (or on Mac) while clicking on the Play button in Transport Toolbar or on the Play-at-Speed button in Play-at-Speed Toolbar. Note that the normal solid Play button will show a vertical split Play Cut Preview.png when the Ctrl (or on Mac) button is held.

In the image below, our selection started at 1.0 seconds. C played the two seconds of audio represented by the overlaid orange arrows. There was only only one second of audio between the start of the track and the selection, so only that was played rather than two seconds, then this was followed immediately by the specified one second after the selection.


Similarly, you can hold Ctrl ( on a Mac) then drag and release in the Timeline to Quick-Play before and after the dragged selection, simulating what a cut would sound like. To hear that Cut Preview repeatedly so as to judge it more easily, click Ctrl + Shift (⌘ + Shift on Mac) then drag in the Timeline.

Bulb icon You may customize almost all keyboard shortcuts. Change them using the Keyboard tab of Preferences.

Play short periods around selections

The following commands play short periods of audio. They were primarily introduced for VI (Visually Impaired) users but will be of benefit to sighted users too:

Action Shortcut
Play short period before selection start Shift + F5
Play short period after selection start Shift + F6
Play short period before selection end Shift + F7
Play short period after selection end Shift + F8
Play short period before and after selection start Ctrl + Shift + F5
Play short period before and after selection end Ctrl + Shift + F7

The periods before and after use the setting of the cut preview as set in Playback Preferences.

Warning icon Note that you must enable the "Full" keyboard shortcut set in Keyboard Preferences for the first four commands in this table to be active.


Mute and Solo buttons

On the Track Control Panel for each track there are two buttons Mute and Solo. These buttons can be used to prevent muted tracks being played on playbck (or exported to an audio file)

Mute Button:

Track Mute button.png Click to silence this track when playing. Click again to unsilence.

Solo Button:

Track Solo button.png Click to play just this track. Click again to release the button. Whenever playing audio, Solo takes precedence over Mute by default - the Mute buttons have no effect whilst any Solo button is down.
There are two other options for Solo button behavior in the Tracks Behaviors Preferences. One of these is to remove the Solo button, leaving only a Mute button. The other is more complex suitable for people used to mixing desks, enabling multiple tracks to be "soloed" simultaneously.
Bulb icon Keyboard shortcuts: Shift+U toggles muting on the currently focused track which has the yellow border, and Shift + S toggles soloing. The solo shortcut works even if you hide the Solo button.



Additional Playback Tips

There are some additional playback tips on this page: Playback Tips.
